Description
- Spec table
| MECH FANSINK | MECH FANSINK |
| H/S DIM. | 367.57*131*13.38mm |
| MATERIAL | AL+CU |
| START/RATED VOLTAGE | 2.5V/5V |
| RATED CURRENT | 0.65(1MAX.)A/0.36(0.55MAX.)A |
| POWER | 3.25W/1.8W |
| RPM | 4300RPM/4200RPM |
| NOISE | 50dB |
| CONNECT PIN/PITCH | 4P/ |
| Excerpt of suitable series | Pulse GL76 12UEK(MS-17L3) Pulse GL76 12UGK(MS-17L3) Pulse GL76 12UGSK(MS-17L3) Pulse GL76 12UEOK(MS-17L3) Pulse GL76 12UGOK(MS-17L3) Sword 17 A12UE(MS-17L3) Sword 17 A12UG(MS-17L3) Katana GF76 12UE(MS-17L3) Katana GF76 12UG(MS-17L3) Katana GF76 12UGS(MS-17L3) Katana GF76 12UEK(MS-17L3) Katana GF76 12UGK(MS-17L3) Katana GF76 12UGSK(MS-17L3) Katana GF76 12UEO(MS-17L3) Katana GF76 12UEOK(MS-17L3) Katana GF76 12UGSO(MS-17L3) |
