Description
- Spec table
| MECH FANSINK | MECH FANSINK |
| H/S DIM. | 391.19*96.89*12.84mm |
| MATERIAL | AL+CU |
| START/RATED VOLTAGE | 5V/ |
| RATED CURRENT | 0.38(0.55MAX.)A |
| POWER | 1.9(2.75MAX.)W |
| RPM | 4350RPM |
| NOISE | 50(53MAX.)dB |
| CONNECT PIN/PITCH | 4P/ |
| Excerpt of suitable series | GF75 Thin 10UEK(MS-17F5) GF75 Thin 10UE(MS-17F5) GF75 Thin 10SCSXR(MS-17F3) GF75 Thin 9SD(MS-17F3) GF75 Thin 9SE(MS-17F3) GF75 Thin 10SER(MS-17F3) GF75 Thin 10SDR(MS-17F3) GF75 Thin 10SDK(MS-17F3) GF75 Thin 10SEK(MS-17F3) GF75 Thin 10SCSXK(MS-17F3) Creator 17M A9SE(MS-17F3) Creator 17M A9SD(MS-17F3) WF75 10TK(MS-17F3) |
